Clavister NetWall

Connect.Protect

Desktop Models

Compare the different Clavister NetWall platforms and choose the desktop model that best fits your specific needs.


E10
E20
E80
E10 Clavister
E20 Clavister
E80 Clavister
Standard
Standard
Pro
Standard
Pro
Firewall performance
1 Gbps
1 Gbps
2 Gbps
2 Gbps
4 Gbps
VPN Performance
100 Mbps
50 Mbps
100 Mbps
500 Mbps
1 Gbps
Concurrent connections
16,000
8,000
16,000
250,000
500,000
Concurrent VPN Tunnels (IPsec)
10
10
25
100
200
Ethernet interfaces
4x 1GbE (RJ45)
2 x 1GbE (RJ45) + 4 x 1GbE (RJ45) switch
6x 1GbE (RJ45)
Virtual Interfaces (VLAN 802.1q)**
16
4
8
64
128
Virtual Routers
2
1
1
5
10
High Availability Support
Optional
Optional
Yes


Hardware Specifications

Rack-mountable
No
Rack-kit included
Power-supply
External PSU, 100-240 VAC, 50-60 Hz
100-240VAC, 50-60 Hz
Recommended Use-Cases

Typical environments
Small offices, branch-offices, CPE

Rackmounted Models

Compare the different Clavister NetWall platforms and choose the rackmounted model that best fits your specific needs.


W20
W30
Standard
Pro
Standard
Pro
Firewall performance
4 Gbps
6 Gbps
6 Gbps
10 Gbps
VPN Performance (Gbps)
1 Gbps
1.5 Gbps
1.5 Gbps
2 Gbps
Concurrent connections
500,000
750,000
750,000
1,000,000
Concurrent VPN Tunnels (IPsec)
500
1,000
1,000
2,000
Ethernet interfaces
6x 1GbE (RJ45)
6x 1GbE (RJ45)
Expansion Slot
No
1
Compatible Modules
-
8 x 1GbE (RJ45 and SFP), 2 or 4 x 10GbE (SFP+)
Virtual Interfaces (VLAN 802.1q)**
256
512
1,024
2,048
Virtual Routers
25
50
50
100
High Availability Support
Yes


Hardware Specifications

Form-Factor
1U 19"
Power-supply
100-240VAC, 50-60 Hz


Recommended Use-Cases

Typical environments
Medium sized offices, regional offices

Virtual Models

Compare the different Clavister NetWall platforms and choose the virtual model that best fits your specific needs.


100V MSSP
500V MSSP
1000V MSSP
2000V MSSP
4000V MSSP
6000V MSSP
Firewall performance*
100 Mbps
500 Mbps
1 Gbps
2 Gbps
4 Gbps
6 Gbps
VPN Performance*
100 Mbps
500 Mbps
1 Gbps
2 Gbps
4 Gbps
6 Gbps
Concurrent connections
8,000
16,000
64,000
128,000
256,000
512,000
Concurrent VPN Tunnels (IPsec)
50
250
500
500
1,000
1,500
Concurrent L2TP/PPTP/SSL VPN Tunnels
50
250
500
500
1,000
1,500
Number of Users
Unrestricted
Unrestricted
Unrestricted
Unrestricted
Unrestricted
Unrestricted
Number of Routing Tables (Virtual Routers)
25
25
50
50
100
100
Ethernet interfaces
Up to 10
Up to 10
Up to 10
Up to 10
Up to 10
Up to 10
Link Aggregation IEEE 802.1AX-2008 (Static/LACP)
Yes
Yes
Yes
Yes
Yes
Yes
Virtual Interfaces (VLAN 802.1q)**
128
128
128
128
128
128
High Availability (HA)**
Yes
Yes
Yes
Yes
Yes
Yes
Service-VLAN Interfaces IEEE 802.1ad (Q-in-Q)
Yes
Yes
Yes
Yes
Yes
Yes
Supported Hypervisors
VMware vSphere, KVM, Microsoft Hyper-V
Minimum Recommended RAM
256 MB
512 MB
512 MB
1 GB
2 GB
4 GB
Recommended Available Storage
256 MB
Number of vCPUs
1
Clavister OS
Clavister cOS Core
Intel AES-NI Crypto Acceleration
Yes
Intel DPDK and SR-IOV Support
Yes
**When using High Availability clusters in virtual environments, the hardware settings for each interface must be identical on both cluster nodes (bus, slot and port).
*Actual performance may vary depending on network conditions, number of activated services and host hardware capabilities.

Clavister NetWall Subscriptions

Clavister Subscriptions ensures that your Next Generation Firewall operates at its peak performance and with best possible protection for your network. The Clavister Subscriptions are available in two different versions giving you the option to choose the one that fits your needs and requirements best.

Clavister Product Subscription

With CPS we provide you with around-the-clock support from our award-winning technical support team. ​
The Clavister Product Subscription keeps your Clavister updated, online and ready for business twenty-four-seven.

Clavister Security Subscription

CSS contains all the services you get with CPS, and includes a full set of next-generation firewall services, such as Application Visibility & Control, Web Content Filtering, Anti Virus Scanning and Network Attack Protection.​ It grants you access to the latest signature updates keeping your infrastructure up to date.

What’s included?

Hardware replacement

24/7 Support

Software replacement

Centralized management with
Clavister InControl

Security analytics with
Clavister InCenter

Signature updates for all the protect and prevent use-cases
